HA7210IB - Renesas Electronics

Description: Programmable Oscillators

Download HA7210IB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
HA7210IB - Renesas Electronics - PCB symbol
click to zoom
PCB Footprints
HA7210IB - Renesas Electronics PCB footprint - Small Outline Packages - Small Outline Packages - M8.15-ren3
click to zoom
3D Models
HA7210IB - Renesas Electronics - 3D model - Small Outline Packages - M8.15-ren3
click to zoom

HA7210IB Details

  • Manufacturer Part Number:

    HA7210IB

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    SOIC-8

  • HTS Code:

    8542.39.00.01

  • Date Of Intro:

    2017-10-24

  • Manufacturer:

    Renesas Electronics Corporation

  • YTEOL:

    0

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    4.9 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max (Vsup):

    7 V

  • Supply Voltage-Min (Vsup):

    2 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    3.9 mm

HA7210IB Frequently Asked Questions (FAQs)

  • Renesas provides a recommended PCB layout guide for the HA7210IB, which includes guidelines for thermal vias, copper pours, and component placement to ensure optimal thermal performance. It's available on the Renesas website or through their support team.
  • The HA7210IB has a built-in overcurrent protection feature, but it requires external components to function. Renesas provides an application note that details the recommended circuit configuration and component values for implementing overcurrent protection.
  • The recommended input capacitor value and type for the HA7210IB depend on the specific application and operating conditions. Renesas provides guidelines for input capacitor selection in their application notes and technical support documentation.
  • Renesas provides a troubleshooting guide for the HA7210IB, which includes steps for identifying and resolving common issues such as overheating, output voltage errors, and oscillation. The guide is available on the Renesas website or through their support team.
  • The HA7210IB has a maximum operating temperature range of -40°C to +125°C, but this can be affected by factors such as PCB layout, thermal design, and ambient temperature. Renesas provides guidelines for thermal design and temperature derating in their datasheet and application notes.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

HA7210IB Overview

Use the download button to access the HA7210IB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like HA721, or try a keyword search, such as Other Signal Circuits
