HAL1823UA-A - TDK

HAL1823UA-A Details

• Manufacturer Part Number:

  HAL1823UA-A

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, TO92UA-2, 3PIN

• Manufacturer:

  TDK Corporation

• YTEOL:

  0

• Additional Feature:

  OVERVOLTAGE, REVERSE VOLTAGE PROTECTION, SHORT-CIRCUIT PROTECTED, IT HAS A SENSITIVITY OF 25 MV/MT, IT ALSO HAVE PACKAGE TO92UA-1

• Body Breadth:

  1.5 mm

• Body Height:

  4.05 mm

• Body Length or Diameter:

  4.06 mm

• Housing:

  PLASTIC

• Hysteresis:

  0.02 mT

• Magnetic Field Range-Max:

  2.8 mT

• Magnetic Field Range-Min:

  -2.8 mT

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  3

• Operating Current-Max:

  10 mA

• Operating Temperature-Max:

  170 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1 mA

• Output Range:

  -1.0-1.0mA

• Output Type:

  CURRENT OUTPUT

• Package Shape/Style:

  RECTANGULAR

• Sensitivity (mV/G):

  250 mV/G

• Sensors/Transducers Type:

  MAGNETIC FIELD SENSOR,HALL EFFECT

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Surface Mount:

  NO

• Termination Type:

  SOLDER
