HAL505UA-A - TDK

HAL505UA-A Details

• Manufacturer Part Number:

  HAL505UA-A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, TO-92UA-1, 3 PIN

• Manufacturer:

  TDK Corporation

• YTEOL:

  0

• Additional Feature:

  REVERSE VOLTAGE PROTECTION

• Body Breadth:

  1.5 mm

• Body Height:

  4.05 mm

• Body Length or Diameter:

  4.06 mm

• Housing:

  PLASTIC

• Hysteresis:

  27 mT

• JESD-609 Code:

  e3

• Magnetic Field Range-Max:

  17 mT

• Magnetic Field Range-Min:

  -17 mT

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  3

• Operating Current-Max:

  4.2 mA

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  20 mA

• Output Range:

  0-20mA

• Output Type:

  ANALOG CURRENT

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  MAGNETIC FIELD SENSOR,HALL EFFECT

• Supply Voltage-Max:

  24 V

• Supply Voltage-Min:

  3.8 V

• Surface Mount:

  NO

• Terminal Finish:

  MATTE TIN

• Termination Type:

  SOLDER
