HCTSM80305BAL-E - Bourns

HCTSM80305BAL-E Details

• Manufacturer Part Number:

  HCTSM80305BAL-E

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7.9

• Application:

  ISOLATION

• Approvals:

  AEC-Q200; IEC

• ET Product-Min:

  11 V-us

• Height:

  6.5 mm

• Isolation Voltage:

  5000 V

• Length:

  12.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, 13 INCH

• Primary Inductance:

  300 µH

• Surface Mount:

  YES

• Transformer Type:

  PULSE TRANSFORMER

• Turns Ratio (Np:Ns):

  3:5

• Width:

  10.8 mm
