HD64F7058BF80L - Renesas Electronics

HD64F7058BF80L Details

• Manufacturer Part Number:

  HD64F7058BF80L

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFP

• Package Description:

  QFP-256

• Pin Count:

  256

• HTS Code:

  8542.31.00.25

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Has ADC:

  YES

• Address Bus Width:

  22

• Bit Size:

  32

• Boundary Scan:

  YES

• CPU Family:

  SH7000

• Clock Frequency-Max:

  20 MHz

• DAC Channels:

  YES

• DMA Channels:

  YES

• External Data Bus Width:

  16

• JESD-30 Code:

  R-PQFP-G256

• JESD-609 Code:

  e0

• Length:

  40 mm

• Number of I/O Lines:

  149

• Number of Terminals:

  256

• On Chip Program ROM Width:

  8

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• PWM Channels:

  YES

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  FQFP

• Package Equivalence Code:

  QFP256,1.2X1.7,20

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK, FINE PITCH

• Qualification Status:

  Not Qualified

• RAM (bytes):

  49152

• ROM (words):

  1048576

• ROM Programmability:

  FLASH

• Seated Height-Max:

  3.56 mm

• Speed:

  80 MHz

• Supply Current-Max:

  150 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3.3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  28 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER, RISC
