HDRA-E68LFDT1+ - HTK

HDRA-E68LFDT1+ Details

• Manufacturer Part Number:

  HDRA-E68LFDT1+

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Honda Tsushin Kogyo Co Ltd

• Body Breadth:

  0.236 inch

• Body Depth:

  0.374 inch

• Body Length:

  1.681 inch

• Contact Finish Mating:

  AU-PD-NI ON NI

• Contact Finish Termination:

  GOLD OVER NICKEL

• Contact Gender:

  FEMALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  70 mΩ

• Dielectric Withstanding Voltage:

  350VAC V

• Insulation Resistance:

  500000000 Ω

• Insulator Color:

  BLACK

• Mating Contact Pitch:

  0.031 inch

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  4

• Number of Rows Loaded:

  2

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.143 mm

• Plating Thickness:

  4u inch

• Rated Current (Signal):

  0.3 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  STEEL

• Terminal Length:

  0.134 inch

• Terminal Pitch:

  1.6002 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  68
