HE1aN-P-DC24V-Y5 - Panasonic

HE1aN-P-DC24V-Y5 Details

• Manufacturer Part Number:

  HE1AN-P-DC24V-Y5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• Factory Lead Time:

  24 Weeks, 6 Days

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  7.67

• Body Breadth:

  33 mm

• Body Height:

  36.3 mm

• Body Length or Diameter:

  38 mm

• Coil Current(DC)-Max:

  0.08 A

• Coil Operate Voltage(DC):

  16.8 V

• Coil Power:

  1920 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  300 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  48A@250VAC

• Contact Current(AC)-Max:

  48 A

• Contact Voltage(AC)-Max:

  250 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  30000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  30 ms

• Operating Temperature-Max:

  55 °C

• Operating Temperature-Min:

  -50 °C

• Packing Method:

  BOX

• Physical Dimension:

  38mm x 33mm x 36.3mm

• Reference Standard:

  UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
