HE721C0500 - HAMLIN

HE721C0500 Details

• Manufacturer Part Number:

  HE721C0500

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Hamlin Electronics

• Body Breadth:

  7.22 mm

• Body Height:

  5.5 mm

• Body Length or Diameter:

  19.5 mm

• Coil Current(DC)-Max:

  0.025 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  125 mW

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  200 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  0.25 A

• Contact (DC) Max Power Rating R Load:

  5W@175VDC

• Contact (DC) Max Rating R Load:

  .25A@175VDC

• Contact Resistance:

  200 mΩ

• Contact Voltage(DC)-Max:

  175 V

• Contact/Output Supply Type:

  DC

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  4

• Operate Time:

  3 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  19.5mm x 7.22mm x 5.5mm

• Reference Standard:

  CUL; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  DRY REED RELAY

• Release Time:

  3 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Length:

  0.002999745999491999 inch

• Termination Type:

  SOLDER
