The recommended operating voltage range for the HEF4082BT-Q100J is 4.5V to 15.5V, as specified in the datasheet. However, it's recommended to operate the device within the 5V to 10V range for optimal performance and reliability.
To ensure proper powering and decoupling, it's recommended to use a 0.1uF to 1uF ceramic capacitor between the VCC pin and GND pin, and a 10uF to 100uF electrolytic capacitor between the VCC pin and GND pin. Additionally, ensure that the power supply is stable and free from noise.
The maximum frequency of operation for the HEF4082BT-Q100J is typically around 10MHz, but it can vary depending on the specific application and operating conditions. It's recommended to consult the datasheet and application notes for more information.
The HEF4082BT-Q100J has a maximum junction temperature of 150°C. To ensure proper thermal management, it's recommended to use a heat sink or thermal pad, and to keep the device away from high-temperature sources. Additionally, ensure that the PCB is designed to dissipate heat efficiently.
The HEF4082BT-Q100J is a 5V device, but it can be used with 3.3V logic levels with some limitations. The device's input threshold voltage is around 2.5V, so it may not work correctly with 3.3V logic levels. It's recommended to use a level shifter or voltage translator to ensure compatibility.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
HEF4082BT-Q100J Overview
Use the download button to access the HEF4082BT-Q100J schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like HEF40,
or try a keyword search, such as Gates
About Nexperia
Nexperia is a leading global player in the semiconductor industry. Specializing in essential electronic components, Nexperia offers a diverse range of products including discrete components, MOSFETs, logic ICs, and analog ICs. These components are integral to a multitude of applications across automotive, industrial, consumer electronics, and computing sectors, where reliability, performance, and efficiency are paramount.
