HF105F-1/012DT-1HSTF - Hongfa

HF105F-1/012DT-1HSTF Details

• Manufacturer Part Number:

  HF105F-1/012DT-1HSTF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  7

• Body Breadth:

  27.1 mm

• Body Height:

  20 mm

• Body Length or Diameter:

  32.3 mm

• Coil Current(DC)-Max:

  0.075 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  900 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  155 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  40A@277VAC

• Contact Current(AC)-Max:

  40 A

• Contact Current(DC)-Max:

  40 A

• Contact (DC) Max Rating R Load:

  40A@28VDC

• Contact Voltage(AC)-Max:

  277 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  32.3mm x 27.1mm x 20mm

• Reference Standard:

  CQC; CUL; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
