HF115F-A/230-2Z4AGF - Hongfa

HF115F-A/230-2Z4AGF Details

• Manufacturer Part Number:

  HF115F-A/230-2Z4AGF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  6.9

• Body Breadth:

  12.7 mm

• Body Height:

  15.7 mm

• Body Length or Diameter:

  29 mm

• Coil Current(AC)-Max:

  0.003 A

• Coil Operate Voltage(AC):

  172.5 V

• Coil Power:

  750 mW

• Coil Release Voltage(AC):

  34.5 V

• Coil Resistance:

  32500 Ω

• Coil Voltage(AC)-Max:

  230 V

• Coil Voltage-Nom:

  230 V

• Coil/Input Supply Type:

  AC

• Contact (AC) Max Power Rating R Load:

  2000VA@440VAC

• Contact (AC) Max Rating R Load:

  8A@440VAC

• Contact Current(AC)-Max:

  8 A

• Contact Current(DC)-Max:

  8 A

• Contact (DC) Max Rating R Load:

  8A@300VDC

• Contact Resistance:

  10 mΩ

• Contact Voltage(AC)-Max:

  440 V

• Contact Voltage(DC)-Max:

  300 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  50000 Cycle(s)

• End Contact Material:

  Silver Tin Oxide

• End Contact Plating:

  Gold

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  29mm x 12.7mm x 15.7mm

• Reference Standard:

  CUL; CQC; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Surface Mount:

  NO

• Terminal Finish:

  Gold (Au)

• Terminal Length:

  0.003606807213614427 inch

• Termination Type:

  SOLDER
