HF2150-1A-24DE - Hongfa

HF2150-1A-24DE Details

• Manufacturer Part Number:

  HF2150-1A-24DE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  7

• Body Breadth:

  27 mm

• Body Height:

  19.1 mm

• Body Length or Diameter:

  31.8 mm

• Coil Current(DC)-Max:

  0.038 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  900 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  660 Ω

• Coil Voltage(DC)-Max:

  31.2 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  11080VA@277VAC

• Contact (AC) Max Rating R Load:

  40A@277VAC

• Contact Current(AC)-Max:

  40 A

• Contact Current(DC)-Max:

  40 A

• Contact (DC) Max Power Rating R Load:

  1200W@30VDC

• Contact (DC) Max Rating R Load:

  40A@30VDC

• Contact Resistance:

  50 mΩ

• Contact Voltage(AC)-Max:

  277 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER CADMIUM OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  4

• Operate Time:

  15 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  31.8mm x 27mm x 19.1mm

• Reference Standard:

  CQC; CUL; TUV; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Terminal Length:

  0.003606807213614427 inch

• Termination Type:

  SOLDER
