HF507S-41-01 - Yamaichi

HF507S-41-01 Details

• Manufacturer Part Number:

  HF507S-41-01

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Yamaichi Electronics Co Ltd

• YTEOL:

  8

• Board Mounting Option:

  FITTING NAIL

• Body Breadth:

  0.171 inch

• Body Depth:

  0.199 inch

• Body Length:

  1.185 inch

• Connector Type:

  FFC/FPC CONNECTOR

• Contact Finish Mating:

  AU ON NI

• Contact Material:

  PHOSPHOR BRONZE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  100 mΩ

• Dielectric Withstanding Voltage:

  170VAC V

• Durability:

  30 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED LIQUID CRYSTAL POLYMER

• Mating Contact Pitch:

  0.02 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• PCB Contact Pattern:

  RECTANGULAR

• Plating Thickness:

  6u inch

• Rated Current (Signal):

  0.3 A

• Terminal Pitch:

  0.508 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  41
