HFCN-5500+ - Mini-Circuits

Description: Signal Conditioning HI PASS FLTR / SURF MT / RoHS

Download HFCN-5500+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
HFCN-5500+ - Mini-Circuits PCB footprint - Other - Other - HFCN-5500+-2
click to zoom
3D Models
HFCN-5500+ - Mini-Circuits  - 3D model - Other - HFCN-5500+-2
click to zoom

HFCN-5500+ Details

  • Manufacturer Part Number:

    HFCN-5500+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    7.24

  • Additional Feature:

    TAPE AND REEL

  • Attenuation Frequency (+/- delta f)-Max:

    1500000 kHz

  • Attenuation Frequency (+/- delta f)-Min:

    1000000 kHz

  • Attenuation@Freq-Max:

    30 dB

  • Attenuation@Freq-Min:

    20 dB

  • Average Input Power:

    7 W

  • Center or Cutoff Frequency (fo/fc):

    5500 MHz

  • Filter Type:

    CERAMIC HPF

  • Height:

    0.89 mm

  • Input/Output Impedance:

    50 OHM

  • Insertion Loss-Max:

    3 dB

  • JESD-609 Code:

    e3

  • Length:

    3.2 mm

  • Mounting Type:

    SURFACE MOUNT

  • Number of Sections-Max:

    5

  • Number of Sections-Min:

    5

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -55 °C

  • Terminal Finish:

    Tin (Sn) - with Nickel (Ni) barrier

  • VSWR:

    1.5

  • Width:

    1.6 mm
