HFCN-8400D+ - Mini-Circuits

Description: Signal Conditioning HI PASS FLTR / SURF MT / RoHS

Download HFCN-8400D+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
HFCN-8400D+ - Mini-Circuits PCB footprint - Other - Other - HFCN-8400D+-1
click to zoom
3D Models
HFCN-8400D+ - Mini-Circuits  - 3D model - Other - HFCN-8400D+-1
click to zoom

HFCN-8400D+ Details

  • Manufacturer Part Number:

    HFCN-8400D+

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    7.24

  • Additional Feature:

    TAPE AND REEL

  • Attenuation Frequency (+/- delta f)-Max:

    2700000 kHz

  • Attenuation Frequency (+/- delta f)-Min:

    2400000 kHz

  • Attenuation@Freq-Max:

    30 dB

  • Attenuation@Freq-Min:

    20 dB

  • Average Input Power:

    7 W

  • Center or Cutoff Frequency (fo/fc):

    8400 MHz

  • Filter Type:

    CERAMIC HPF

  • Height:

    0.89 mm

  • Input/Output Impedance:

    50 OHM

  • Insertion Loss-Max:

    3 dB

  • JESD-609 Code:

    e3

  • Length:

    3.2 mm

  • Mounting Type:

    SURFACE MOUNT

  • Number of Sections-Max:

    5

  • Number of Sections-Min:

    5

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    100 °C

  • Operating Temperature-Min:

    -55 °C

  • Screening Level:

    MIL-STD-202

  • Terminal Finish:

    Tin (Sn) - with Nickel (Ni) barrier

  • VSWR:

    1.5

  • Width:

    1.6 mm

HFCN-8400D+ Frequently Asked Questions (FAQs)

  • A good grounding scheme is crucial for the HFCN-8400D+. It's recommended to use a solid ground plane on the PCB, and to connect the device's ground pins to the ground plane using vias. Additionally, keep the signal traces short and away from noise sources.
  • The HFCN-8400D+ requires a bias voltage of 5V and a bias current of 100mA. Ensure that the power supply is stable and noise-free, and that the bias voltage is applied correctly to the device's VCC pin.
  • The HFCN-8400D+ can handle input powers up to +10dBm. Exceeding this limit may cause damage to the device or affect its performance.
  • Common issues like oscillations or instability can be caused by improper biasing, poor PCB layout, or inadequate decoupling. Check the bias voltage and current, ensure proper grounding, and add decoupling capacitors if necessary. Also, verify that the input and output impedances are matched correctly.
  • The HFCN-8400D+ is designed to operate within a temperature range of -40°C to +85°C. Operating outside this range may affect the device's performance or reliability.
