HFD2/005-S-L2-D - Hongfa

HFD2/005-S-L2-D Details

• Manufacturer Part Number:

  HFD2/005-S-L2-D

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  7.75

• Body Breadth:

  10.2 mm

• Body Height:

  10.6 mm

• Body Length or Diameter:

  20.2 mm

• Coil Current(DC)-Max:

  0.03 A

• Coil Operate Voltage(DC):

  4 V

• Coil Power:

  150 mW

• Coil Release Voltage(DC):

  4 V

• Coil Resistance:

  167 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  3A@250VAC

• Contact Current(AC)-Max:

  3 A

• Contact Current(DC)-Max:

  3 A

• Contact (DC) Max Rating R Load:

  3A@220VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  220 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  50000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  4.5 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20.2mm x 10.2mm x 10.6mm

• Reference Standard:

  CUL; UL

• Relay Action:

  LATCHED

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  4.5 ms

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER
