HFD27/012-H - Hongfa

HFD27/012-H Details

• Manufacturer Part Number:

  HFD27/012-H

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  6.75

• Body Breadth:

  10 mm

• Body Height:

  11.5 mm

• Body Length or Diameter:

  20.2 mm

• Coil Current(DC)-Max:

  0.013 A

• Coil Operate Voltage(DC):

  9.6 V

• Coil Power:

  150 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  960 Ω

• Coil Voltage(DC)-Max:

  27.7 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  125VA@240VAC

• Contact (AC) Max Rating R Load:

  2A@240VAC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact (DC) Max Power Rating R Load:

  60W@120VDC

• Contact (DC) Max Rating R Load:

  2A@120VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  240 V

• Contact Voltage(DC)-Max:

  120 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER NICKEL

• End Contact Plating:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  7 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20.2mm x 10mm x 11.5mm

• Reference Standard:

  CQC; CUL; TUV; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  4 ms

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Length:

  0.003098806197612395 inch

• Termination Type:

  SOLDER
