HFE60/12-1HST-L2 - Hongfa

HFE60/12-1HST-L2 Details

• Manufacturer Part Number:

  HFE60/12-1HST-L2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  7

• Body Breadth:

  11.3 mm

• Body Height:

  10.5 mm

• Body Length or Diameter:

  20.2 mm

• Coil Current(DC)-Max:

  0.025 A

• Coil Operate Voltage(DC):

  9.6 V

• Coil Power:

  300 mW

• Coil Release Voltage(DC):

  9.6 V

• Coil Resistance:

  480 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  8A@380VAC

• Contact Current(AC)-Max:

  8 A

• Contact Current(DC)-Max:

  8 A

• Contact (DC) Max Rating R Load:

  8A@240VDC

• Contact Voltage(AC)-Max:

  380 V

• Contact Voltage(DC)-Max:

  240 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  30000 Cycle(s)

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20.2mm x 11.3mm x 10.5mm

• Reference Standard:

  CUL; TUV; UL

• Relay Action:

  LATCHED

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Sealing:

  MOISTURE PROOF

• Surface Mount:

  NO

• Terminal Finish:

  GOLD

• Termination Type:

  SOLDER
