HFK10-T/12-SHST - Hongfa

HFK10-T/12-SHST Details

• Manufacturer Part Number:

  HFK10-T/12-SHST

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  7.35

• Body Breadth:

  15.9 mm

• Body Height:

  17 mm

• Body Length or Diameter:

  18.85 mm

• Coil Current(DC)-Max:

  0.038 A

• Coil Operate Voltage(DC):

  7.3 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  1 V

• Coil Resistance:

  320 Ω

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  60 A

• Contact (DC) Max Rating R Load:

  60A@13.5VDC

• Contact Voltage(DC)-Max:

  13.5 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  6

• Operate Time:

  10 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  18.85mm x 15.9mm x 17mm

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM U

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  3 ms

• Surface Mount:

  NO

• Terminal Length:

  0.003599187198374397 inch

• Termination Type:

  SOLDER
