HFKC/012-ZSPT - Hongfa

HFKC/012-ZSPT Details

• Manufacturer Part Number:

  HFKC/012-ZSPT

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  6

• Additional Feature:

  AUTOMOTIVE APPLICATION

• Body Breadth:

  12 mm

• Body Height:

  9.9 mm

• Body Length or Diameter:

  12.9 mm

• Coil Current(DC)-Max:

  0.067 A

• Coil Operate Voltage(DC):

  9.9 V

• Coil Power:

  800 mW

• Coil Release Voltage(DC):

  1.5 V

• Coil Resistance:

  181 Ω

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  30 A

• Contact (DC) Max Rating R Load:

  30A@16VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(DC)-Max:

  16 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  300000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  5

• Operate Time:

  10 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  12.9mm x 12mm x 9.9mm

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  2 ms

• Surface Mount:

  NO

• Terminal Length:

  0.0027940055880111762 inch

• Termination Type:

  SOLDER
