HFV16-P/12-HST(150) - Hongfa

HFV16-P/12-HST(150) Details

• Manufacturer Part Number:

  HFV16-P/12-HST(150)

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Manufacturer:

  Xiamen Hongfa Electroacoustic Co.,Ltd.

• YTEOL:

  6.77

• Body Breadth:

  26 mm

• Body Height:

  22.7 mm

• Body Length or Diameter:

  26.6 mm

• Coil Current(DC)-Max:

  0.15 A

• Coil Operate Voltage(DC):

  7.2 V

• Coil Power:

  1800 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  90 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  70 A

• Contact (DC) Max Rating R Load:

  70A@13.5VDC

• Contact Voltage(DC)-Max:

  13.5 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  26.6mm x 26mm x 22.7mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
