HLMP-2300 - Avago Technologies

HLMP-2300 Details

• Manufacturer Part Number:

  HLMP-2300

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• HTS Code:

  8541.40.20.00

• Manufacturer:

  Avago Technologies

• YTEOL:

  7

• Color:

  HIGH EFFICIENCY RED

• Color@Wavelength:

  Red

• Configuration:

  SEPARATE, 2 ELEMENTS

• Forward Current-Max:

  0.03 A

• Forward Voltage-Max:

  2.6 V

• JESD-609 Code:

  e1

• Luminous Intensity-Min:

  0.0045 cd

• Luminous Intensity-Nom:

  23 mcd

• Mounting Feature:

  RADIAL MOUNT

• Number of Functions:

  1

• Number of LEDs in Array:

  2

• Number of Terminals:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Optoelectronic Device Type:

  SINGLE COLOR LED

• Overall Height:

  6.223 mm

• Packing Method:

  BULK

• Peak Wavelength:

  635 nm

• Shape:

  RECTANGULAR

• Size:

  8.89 mm

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Pitch:

  2.54 mm
