HMC383LC4 - Analog Devices

Description: ANALOG DEVICES - HMC383LC4 - RF AMP, 13DB, 12-30GHZ, 5.5V, QFN-24

Download HMC383LC4 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
HMC383LC4 - Analog Devices - PCB symbol
click to zoom
PCB Footprints
HMC383LC4 - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 24-SMT (4x4)
click to zoom
3D Models
HMC383LC4 - Analog Devices - 3D model - Quad Flat No-Lead - 24-SMT (4x4)
click to zoom

HMC383LC4 Details

  • Manufacturer Part Number:

    HMC383LC4

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    4 X 4 MM, ROHS COMPLIANT, LEADLESS, ALUMINIUM, SMT, 24 PIN

  • Pin Count:

    24

  • Manufacturer Package Code:

    HE-24-1

  • Country Of Origin:

    USA

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Gain:

    10 dB

  • Input Power-Max (CW):

    10 dBm

  • JESD-609 Code:

    e4

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Frequency-Max:

    30000 MHz

  • Operating Frequency-Min:

    12000 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    LCC24,.16SQ,20

  • Power Supplies:

    5 V

  • RF/Microwave Device Type:

    WIDE BAND LOW POWER

  • Supply Current-Max:

    135 mA

  • Surface Mount:

    YES

  • Technology:

    GAAS

  • Terminal Finish:

    Gold (Au)

HMC383LC4 Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a separate power plane is recommended. Keep the signal traces short and away from the power plane to minimize noise coupling.
  • The HMC383LC4 requires a single +5V power supply. Ensure the power supply is well-regulated and decoupled with 0.1uF and 10uF capacitors. The Vcc pin should be connected to a clean power source, and the Vee pin should be connected to a quiet ground.
  • The HMC383LC4 can operate up to 6 GHz, but the maximum operating frequency depends on the specific application and the quality of the PCB layout. In general, it's recommended to operate the device at frequencies below 4 GHz for optimal performance.
  • To minimize the noise figure, ensure the input signal is properly matched to the device, and the output is properly terminated. Use a low-noise power supply, and keep the device away from noise sources. Additionally, use a high-quality PCB material and ensure good thermal management.
  • The recommended operating temperature range for the HMC383LC4 is -40°C to +85°C. However, the device can operate up to +100°C with reduced performance and reliability.
