HMC470ATCPZ-EP-RL7 - Analog Devices

HMC470ATCPZ-EP-RL7 Details

• Manufacturer Part Number:

  HMC470ATCPZ-EP-RL7

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  MO-220-VEED-4, 16 PIN

• Pin Count:

  16

• Manufacturer Package Code:

  CP-16-51

• Country Of Origin:

  South Korea

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  8.5

• Additional Feature:

  CMOS COMPATIBLE

• Attenuation-Nom:

  31 dB

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  25 dBm

• Insertion Loss-Max:

  2 dB

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  16

• Operating Frequency-Max:

  3000 MHz

• Operating Frequency-Min:

  100 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC16,.12SQ,20

• Power Supplies:

  3/5 V

• RF/Microwave Device Type:

  VARIABLE ATTENUATOR

• Surface Mount:

  YES

• Technology:

  GAAS

• VSWR-Max:

  1.5
