HMC641ATCPZ-EP-RL7 - Analog Devices

HMC641ATCPZ-EP-RL7 Details

• Manufacturer Part Number:

  HMC641ATCPZ-EP-RL7

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LFCSP-24

• Pin Count:

  24

• Manufacturer Package Code:

  CP-24-22

• Country Of Origin:

  South Korea

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• 1dB Compression Point:

  22 dBm

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  17 dBm

• Isolation-Min:

  30 dB

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  24

• On Time-Nom:

  0.1 µs

• Operating Frequency-Max:

  20000 MHz

• Operating Frequency-Min:

  100 MHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC24,.16SQ,20

• Port Termination:

  ABSORPTIVE

• Power Supplies:

  -3/-5 V

• RF/Microwave Device Type:

  SP4T

• Supply Current-Max:

  5 mA

• Surface Mount:

  YES

• Technology:

  GAAS
