HMC700LP4ETR - Analog Devices

Description: 8 GHz 16-Bit Fractional-N PLL

Download HMC700LP4ETR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
HMC700LP4ETR - Analog Devices - PCB symbol
click to zoom
PCB Footprints
HMC700LP4ETR - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - HMC750LP4E
click to zoom
3D Models
HMC700LP4ETR - Analog Devices - 3D model - Quad Flat No-Lead - HMC750LP4E
click to zoom

HMC700LP4ETR Details

  • Manufacturer Part Number:

    HMC700LP4ETR

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    4 X 4 MM, ROHS COMPLIANT, PLASTIC, SMT-24

  • Pin Count:

    24

  • Manufacturer Package Code:

    HCP-24-2

  • Country Of Origin:

    South Korea

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn)

  • Time@Peak Reflow Temperature-Max (s):

    30

HMC700LP4ETR Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and thermal vias is recommended. Ensure good thermal conductivity by using a thermal pad and a heat sink if necessary.
  • Use a combination of ceramic and electrolytic capacitors with a total capacitance of at least 10uF, and place them as close to the device as possible. Ensure the power supply lines are well-filtered and decoupled.
  • Use a low-jitter clock source, and ensure the clock signal is properly terminated and filtered. A clock frequency of 100MHz to 200MHz is recommended for optimal performance.
  • Use controlled impedance traces, and ensure signal lines are properly terminated and shielded. Minimize signal reflections by using series termination and AC coupling. Use EMI filters and shielding if necessary.
  • Use the Analog Devices Inc. evaluation board and software development kit (SDK) to program and configure the device. Follow the recommended programming sequence and configuration guidelines.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

HMC700LP4ETR Overview

Use the download button to access the HMC700LP4ETR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like HMC70, or try a keyword search, such as PLL or Frequency Synthesis Circuits

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
