HMC720LP3E - Analog Devices

HMC720LP3E Details

• Manufacturer Part Number:

  HMC720LP3E

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LCC-16

• Pin Count:

  16

• Manufacturer Package Code:

  HCP-16-3

• Country Of Origin:

  South Korea

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Family:

  ECL

• Input Conditioning:

  DIFFERENTIAL

• JESD-30 Code:

  S-PQCC-N16

• JESD-609 Code:

  e3

• Length:

  3 mm

• Logic IC Type:

  LOW SKEW CLOCK DRIVER

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  16

• Number of True Outputs:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC16,.12SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Power Supply Current-Max (ICC):

  90 mA

• Prop. Delay@Nom-Sup:

  0.12 ns

• Propagation Delay (tpd):

  0.12 ns

• Seated Height-Max:

  1 mm

• Supply Voltage-Max (Vsup):

  -3.6 V

• Supply Voltage-Min (Vsup):

  -3 V

• Supply Voltage-Nom (Vsup):

  -3.3 V

• Surface Mount:

  YES

• Technology:

  ECL

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  3 mm
