HMC734LP5TR - Analog Devices

HMC734LP5TR Details

• Manufacturer Part Number:

  HMC734LP5TR

• Brand Name:

  Analog Devices Inc

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Package Description:

  LEADLESS, QFN, 32 PIN

• Pin Count:

  32

• Manufacturer Package Code:

  HCP-32-1

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Analog Devices Inc

• YTEOL:

  9

• Control Voltage-Max:

  13 V

• Control Voltage-Min:

  1 V

• Modulation Sensitivity:

  30 MHz/V

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  32

• Offset Frequency:

  100 kHz

• Operating Frequency-Max:

  10200 MHz

• Operating Frequency-Min:

  8600 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  VOLTAGE CONTROLLED OSCILLATOR

• Output Power:

  22 dBm

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  LCC32,.2SQ,20

• Phase Noise:

  -100 dBc/Hz

• Physical Dimension:

  5.1mm x 5.1mm x 1.0mm

• Supply Current-Max:

  240 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES
