HMC831LP6CE - Analog Devices

Description: Fractional-N PLL with Integrated VCO SMT, 1815 - 2010 MHz 40-VFQFN Exposed Pad

Download HMC831LP6CE Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
HMC831LP6CE - Analog Devices - PCB symbol
click to zoom
PCB Footprints
HMC831LP6CE - Analog Devices PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 40-VFQFN Exposed Pad
click to zoom
3D Models
HMC831LP6CE - Analog Devices - 3D model - Quad Flat No-Lead - 40-VFQFN Exposed Pad
click to zoom

HMC831LP6CE Details

  • Manufacturer Part Number:

    HMC831LP6CE

  • Brand Name:

    Analog Devices Inc

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    SMT-40

  • Pin Count:

    40

  • Manufacturer Package Code:

    HCP-40-1

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    0

  • Analog IC - Other Type:

    PHASE LOCKED LOOP

  • JESD-30 Code:

    S-PQCC-N40

  • JESD-609 Code:

    e3

  • Length:

    6 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    40

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    0.9 mm

  • Supply Voltage-Max (Vsup):

    3.5 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    6 mm

HMC831LP6CE Frequently Asked Questions (FAQs)

  • A good PCB layout for the HMC831LP6CE involves keeping the signal paths short, using a solid ground plane, and minimizing the distance between the device and the antenna. It's also recommended to use a 4-layer PCB with a dedicated layer for the RF signal, a layer for the ground plane, and two layers for the power supply and control signals.
  • To ensure proper biasing, make sure to follow the recommended voltage and current settings outlined in the datasheet. The HMC831LP6CE requires a single supply voltage of 3.3V to 5V, and the recommended bias current is 20mA to 40mA. Additionally, ensure that the bias voltage is well-regulated and noise-free to prevent any performance degradation.
  • The HMC831LP6CE can handle a maximum input power of +20dBm (100mW) without any damage. However, it's recommended to operate the device at a maximum input power of +15dBm (30mW) to ensure optimal performance and reliability.
  • To troubleshoot common issues with the HMC831LP6CE, start by checking the PCB layout and ensuring that it meets the recommended layout guidelines. Next, verify that the device is properly biased and that the supply voltage is well-regulated. Also, check for any signs of damage or overheating, and ensure that the device is operated within its recommended operating conditions. If the issue persists, consult the datasheet and application notes for further troubleshooting guidance.
  • Yes, the HMC831LP6CE can be used in a switching application. The recommended switching frequencies depend on the specific application, but in general, the device can be switched at frequencies up to 100kHz. However, it's recommended to consult the datasheet and application notes for specific guidance on switching frequencies and protocols.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

HMC831LP6CE Overview

Use the download button to access the HMC831LP6CE schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like HMC83, or try a keyword search, such as PLL or Frequency Synthesis Circuits

About Analog Devices

Analog Devices Inc. is a global leader in the design and manufacturing of analog, mixed-signal, and digital signal processing integrated circuits and software solutions for the industrial, automotive, healthcare, communications industries. Analog Devices serves a diverse range of markets including industrial, automotive, healthcare, energy, aerospace, defense, and consumer electronics industries. Analog Devices’ product portfolio includes a wide range of ICs, modules, and subsystems.
