HMT7742 - HMT Microelectronic

HMT7742 Details

• Manufacturer Part Number:

  HMT7742

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  DFN-12

• HTS Code:

  8542.39.00.01

• Manufacturer:

  HMT microelectronic AG

• Interface IC Type:

  INTERFACE CIRCUIT

• JESD-30 Code:

  R-PDSO-N12

• Length:

  4 mm

• Number of Functions:

  1

• Number of Terminals:

  12

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC12,.12,20

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  0.8 mm

• Supply Voltage-Max:

  35 V

• Supply Voltage-Min:

  5 V

• Supply Voltage-Nom:

  24 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Width:

  3 mm
