HN58C1001P-15 - HITACHI

HN58C1001P-15 Details

• Manufacturer Part Number:

  HN58C1001P-15

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  DIP

• Package Description:

  0.600 INCH, PLASTIC, DIP-32

• Pin Count:

  32

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  Hitachi Ltd

• Access Time-Max:

  150 ns

• Additional Feature:

  10K ERASE/WRITE CYCLES; DATA RETENTION 10 YEARS

• Command User Interface:

  NO

• Data Polling:

  YES

• Data Retention Time-Min:

  10

• JESD-30 Code:

  R-PDIP-T32

• JESD-609 Code:

  e0

• Length:

  41.9 mm

• Memory Density:

  1048576 bit

• Memory IC Type:

  EEPROM

• Memory Width:

  8

• Number of Functions:

  1

• Number of Terminals:

  32

• Number of Words:

  131072 words

• Number of Words Code:

  128000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  128KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP32,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Page Size:

  128 words

• Parallel/Serial:

  PARALLEL

• Programming Voltage:

  5 V

• Qualification Status:

  Not Qualified

• Ready/Busy:

  YES

• Seated Height-Max:

  5.08 mm

• Standby Current-Max:

  0.00002 A

• Supply Current-Max:

  0.05 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Toggle Bit:

  YES

• Width:

  15.24 mm

• Write Cycle Time-Max (tWC):

  10 ms
