HP0315AFKP2-S - NKK Switches

HP0315AFKP2-S Details

• Manufacturer Part Number:

  HP0315AFKP2-S

• Brand Name:

  NKK Switches

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  NKK Switches

• YTEOL:

  9

• Actuator Color:

  BLACK

• Actuator Material:

  GLASS FILLED POLYAMIDE

• Actuator Travel:

  0.2 mm

• Actuator Type:

  FLAT BUTTON TYPE

• Additional Feature:

  APPROVAL: UL

• Body Breadth:

  6.2 mm

• Body Height:

  3.6 mm

• Body Length or Diameter:

  6.2 mm

• Center Contact Material:

  STAINLESS STEEL

• Center Contact Plating:

  SILVER

• Circuit Configuration:

  1X1

• Contact Current(DC)-Max:

  0.11 A

• Contact (DC) Max Power Rating R Load:

  3VA@28VDC

• Contact (DC) Max Rating R Load:

  0.11A@28VDC

• Contact Function:

  OFF-(ON)

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  28 V

• Dielectric Withstand Volts:

  250VAC V

• Electrical Life:

  500000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  SILVER

• Housing Material:

  STAINLESS STEEL

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  GLASS FILLED POLYAMIDE

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  1.6 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TUBE

• Solderability:

  HAND; REFLOW

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Finish:

  SILVER

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER

• Washability:

  SOLVENT
