HP1-1400LB - COILCRAFT

HP1-1400LB Details

• Manufacturer Part Number:

  HP1-1400LB

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  0

• Case/Size Code:

  5136

• Construction:

  Rectangular

• Core Material:

  FERRITE

• DC Resistance:

  0.145 Ω

• Inductance-Nom (L):

  89.6 µH

• Inductor Application:

  DC-DC CONVERTER

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  6

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  6.2 mm

• Package Length:

  13 mm

• Package Style:

  SMT

• Package Width:

  9.2 mm

• Packing Method:

  TR

• Rated Current-Max:

  0.74 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver - Matte Tin - with Nickel barrier

• Terminal Placement:

  DUAL IN-LINE

• Terminal Shape:

  GULL WING

• Test Frequency:

  0.1 MHz

• Tolerance:

  25%
