HP6-0121L - COILCRAFT

HP6-0121L Details

• Manufacturer Part Number:

  HP6-0121L

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  6.4

• Construction:

  Rectangular

• Core Material:

  FERRITE

• DC Resistance:

  0.02 Ω

• Inductance-Nom (L):

  4.36 µH

• Inductor Application:

  DC-DC CONVERTER

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  6

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  13.6 mm

• Package Length:

  32.65 mm

• Package Style:

  SMT

• Package Width:

  26.75 mm

• Packing Method:

  Tray

• Rated Current-Max:

  3.5 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  YES

• Terminal Placement:

  DUAL IN-LINE

• Terminal Shape:

  GULL WING

• Test Frequency:

  0.1 MHz

• Tolerance:

  10%
