HR30-8R-12SD(71) - Hirose

HR30-8R-12SD(71) Details

• Manufacturer Part Number:

  HR30-8R-12SD(71)

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Hirose Electric Co Ltd

• YTEOL:

  0

• Additional Feature:

  IPX7; IPX8; LOW PROFILE

• Backshell Type:

  SOLID

• Body Depth:

  0.366 inch

• Body Diameter:

  0.59 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  CIRCULAR CONNECTOR

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  FEMALE

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Empty Shell:

  NO

• Environmental Characteristics:

  ENVIRONMENT RESISTANT

• Filter Feature:

  NO

• Insulator Material:

  POLYACETAL/POLYBUTYLENE TEREPHTHALATE/POLYPHENYLENE SULFIDE

• JESD-609 Code:

  e4

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Type:

  BOARD AND PANEL

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  WATERPROOF

• Reference Standard:

  UL

• Shell Size:

  8

• Termination Type:

  SOLDER

• Total Number of Contacts:

  12
