HRM2-S-DC5V-C - Multicomp Pro

HRM2-S-DC5V-C Details

• Manufacturer Part Number:

  HRM2-S-DC5V-C

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  SPC Multicomp

• Body Breadth:

  12.6 mm

• Body Height:

  20.8 mm

• Body Length or Diameter:

  29 mm

• Coil Current(DC)-Max:

  0.144 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  720 mW

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  35 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  16A@250VAC

• Contact Current(AC)-Max:

  16 A

• Contact Current(DC)-Max:

  16 A

• Contact (DC) Max Rating R Load:

  16A@30VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  55 °C

• Operating Temperature-Min:

  -30 °C

• Physical Dimension:

  29mm x 12.6mm x 20.8mm

• Relay Action:

  MOMENTARY

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  8 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
