HT45R0072 - Holtek

HT45R0072 Details

• Manufacturer Part Number:

  HT45R0072

• Part Life Cycle Code:

  Obsolete

• Package Description:

  QFN-46

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Holtek Semiconductor Inc

• YTEOL:

  0

• Has ADC:

  NO

• Bit Size:

  8

• Boundary Scan:

  NO

• CPU Family:

  HT45

• Clock Frequency-Max:

  12 MHz

• DAC Channels:

  NO

• DMA Channels:

  NO

• Format:

  FIXED POINT

• Integrated Cache:

  NO

• JESD-30 Code:

  R-XQCC-N46

• Length:

  6.5 mm

• Low Power Mode:

  YES

• Number of I/O Lines:

  34

• Number of Terminals:

  46

• Number of Timers:

  2

• On Chip Data RAM Width:

  8

• On Chip Program ROM Width:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PWM Channels:

  NO

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC46,.17X.25,16

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• RAM (bytes):

  160

• ROM (words):

  4096

• ROM Programmability:

  FLASH

• Seated Height-Max:

  0.9 mm

• Speed:

  12 MHz

• Supply Current-Max:

  16 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3.3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Width:

  4.5 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER, RISC
