HT66F0182 - Holtek

HT66F0182 Details

• Manufacturer Part Number:

  HT66F0182

• Part Life Cycle Code:

  Active

• Package Description:

  NSOP-16

• HTS Code:

  8542.31.00.15

• Manufacturer:

  Holtek Semiconductor Inc

• YTEOL:

  7.1

• Has ADC:

  YES

• Bit Size:

  8

• Boundary Scan:

  NO

• Clock Frequency-Max:

  8 MHz

• DAC Channels:

  NO

• DMA Channels:

  NO

• Format:

  FIXED POINT

• Integrated Cache:

  NO

• JESD-30 Code:

  R-PDSO-G16

• Length:

  9.9 mm

• Low Power Mode:

  YES

• Number of External Interrupts:

  2

• Number of I/O Lines:

  18

• Number of Terminals:

  16

• On Chip Data RAM Width:

  8

• On Chip Program ROM Width:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PWM Channels:

  YES

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP16,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• RAM (bytes):

  128

• ROM (words):

  4096

• ROM Programmability:

  FLASH

• Seated Height-Max:

  1.75 mm

• Speed:

  8 MHz

• Supply Current-Max:

  2.4 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  3 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  3.9 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER, RISC
