HX15-P - LEM

HX15-P Details

• Manufacturer Part Number:

  HX15-P

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Japan

• Manufacturer:

  LEM Holdings SSA

• Additional Feature:

  IT ALSO REQUIRES OPERATES AT PLUS/MINUS 12V

• Body Breadth:

  15.4 mm

• Body Height:

  19.5 mm

• Body Length or Diameter:

  19 mm

• Housing:

  PLASTIC

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Output Range:

  -4-4V

• Output Type:

  ANALOG VOLTAGE

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  CURRENT SENSOR

• Supply Voltage-Max:

  15.75 V

• Supply Voltage-Min:

  14.25 V

• Surface Mount:

  NO

• Termination Type:

  SOLDER
