I538-2P3-16.384MHZ - ABRACON

I538-2P3-16.384MHZ Details

• Manufacturer Part Number:

  I538-2P3-16.384MHZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 4 PIN

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6.6

• Aging:

  1 PPM/YEAR

• Fall Time-Max:

  10 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  2%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  16.384 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  LCC4,.1X.12,94/60

• Physical Dimension:

  3.2mm x 2.5mm x 1.2mm

• Rise Time-Max:

  10 ns

• Supply Current-Max:

  6 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  60/40 %
