IAUZ30N06S5L140ATMA1 - Infineon

Description: MOSFET N-CH 60V 30A TSDSON-8-32

Download IAUZ30N06S5L140ATMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
IAUZ30N06S5L140ATMA1 - Infineon PCB footprint - Other - Other - PG-TSDSON-8-32_2019
click to zoom
3D Models
IAUZ30N06S5L140ATMA1 - Infineon  - 3D model - Other - PG-TSDSON-8-32_2019
click to zoom

IAUZ30N06S5L140ATMA1 Details

  • Manufacturer Part Number:

    IAUZ30N06S5L140ATMA1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Germany, Malaysia

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    26 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    5

  • Avalanche Energy Rating (Eas):

    27 mJ

  • Case Connection:

    DRAIN

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    60 V

  • Drain Current-Max (ID):

    30 A

  • Drain-source On Resistance-Max:

    0.0196 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    15 pF

  • JESD-30 Code:

    S-PDSO-N8

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    1

  • Number of Terminals:

    8

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    175 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    N-CHANNEL

  • Power Dissipation-Max (Abs):

    33 W

  • Pulsed Drain Current-Max (IDM):

    85 A

  • Reference Standard:

    AEC-Q101

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Transistor Element Material:

    SILICON

IAUZ30N06S5L140ATMA1 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the IAUZ30N06S5L140ATMA1 is -55°C to 175°C.
  • To minimize switching losses, ensure the gate drive voltage is sufficient (typically 10-15V), and the gate resistance is minimized (e.g., using a low-impedance gate driver).
  • To minimize parasitic inductance and capacitance, use a compact PCB layout with short, wide traces, and place the MOSFET close to the driver. Avoid using vias under the MOSFET, and use a solid ground plane.
  • Use a voltage clamp or a zener diode to protect against overvoltage, and implement overcurrent protection using a current sense resistor and a comparator or a dedicated overcurrent protection IC.
  • The recommended gate resistor value depends on the specific application, but a typical value is in the range of 10-100 ohms. A lower value can reduce switching losses, but may increase oscillations.
