IC149-080-012-B5 - Yamaichi

IC149-080-012-B5 Details

• Manufacturer Part Number:

  IC149-080-012-B5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Yamaichi Electronics Co Ltd

• YTEOL:

  6.5

• Body Breadth:

  0.551 inch

• Body Depth:

  0.12 inch

• Body Length:

  0.787 inch

• Contact Configuration:

  20X20

• Contact Finish Termination:

  Gold (Au)

• Contact Style:

  BELLOWED TYPE

• Current Rating:

  0.5 A

• Device Socket Type:

  IC SOCKET

• Device Type Used On:

  QFP80

• Dielectric Withstanding Voltage:

  700VAC V

• Housing Material:

  GLASS FILLED POLYAMIDE/POLYPHENYLENE SULFIDE

• Insulation Resistance:

  500000000 Ω

• JESD-609 Code:

  e4

• Mating Contact Pitch:

  0.031 inch

• Mounting Style:

  STRAIGHT

• Number of Contacts:

  80

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  1.2716535433070866 mm

• Terminal Pitch:

  0.8 mm

• Termination Type:

  SURFACE MOUNT
