IC160Z-0284-240 - Yamaichi

IC160Z-0284-240 Details

• Manufacturer Part Number:

  IC160Z-0284-240

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Yamaichi Electronics Co Ltd

• YTEOL:

  6.83

• Additional Feature:

  LOW PROFILE; UL 94V-0

• Body Breadth:

  0.669 inch

• Body Depth:

  0.197 inch

• Body Length:

  0.669 inch

• Contact Configuration:

  7X7

• Contact Finish Mating:

  TIN BISMUTH

• Contact Finish Termination:

  Tin/Bismuth (Sn/Bi)

• Contact Material:

  COPPER ALLOY

• Contact Style:

  BELLOWED TYPE

• Current Rating:

  1 A

• Device Socket Type:

  IC SOCKET

• Device Type Used On:

  PLCC28

• Dielectric Withstanding Voltage:

  350VAC V

• Housing Material:

  POLYAMIDE

• Insulation Resistance:

  500000000 Ω

• JESD-609 Code:

  e6

• Mounting Style:

  STRAIGHT

• Number of Contacts:

  28

• Termination Type:

  SURFACE MOUNT
