iEH48025A120V-003-R - TDK Lambda

iEH48025A120V-003-R Details

• Manufacturer Part Number:

  IEH48025A120V-003-R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  Module-5

• ECCN Code:

  EAR99

• Manufacturer:

  TDK-Lambda Corporation

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CB, CE, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  94.6%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• JESD-30 Code:

  R-XDMA-P5

• Length:

  50.8 mm

• Line Regulation-Max:

  0.0072%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  130 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  25 A

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER VOLTAGE; OVER LOAD; THERMAL

• Ripple Voltage (Main Out):

  0.04242 Vrms

• Seated Height-Max:

  13.26 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  300 W

• Trim/Adjustable Output:

  NO

• Width:

  22.86 mm
