Vishay provides a recommended PCB layout and land pattern in their application note AN10343, which can be found on their website. It's essential to follow this layout to ensure proper thermal performance and to prevent thermal runaway.
The choice of TIM depends on the specific application and operating conditions. Vishay recommends using a TIM with a thermal conductivity of at least 3 W/m-K and a thickness of 0.05 mm to 0.15 mm. Some popular TIM options include thermal grease, thermal tape, and graphite sheets.
According to Vishay's application note AN10273, the maximum allowed voltage derating for the IHB5EB101K is 80% of the maximum rated voltage. This means that if the maximum rated voltage is 1000 V, the maximum allowed voltage derating would be 800 V.
To ensure proper soldering, follow Vishay's recommended soldering profile, which can be found in their application note AN10343. It's essential to use a solder with a melting point above 220°C and to avoid excessive soldering temperatures, which can damage the component.
Vishay recommends storing the IHB5EB101K in a dry, cool place, away from direct sunlight and moisture. The components should be stored in their original packaging or in a similar ESD-protective package. Handling should be done with ESD-protective equipment and clothing to prevent damage from electrostatic discharge.
