IHDF1300AEEH3R3K1A - Vishay

IHDF1300AEEH3R3K1A Details

• Manufacturer Part Number:

  IHDF1300AEEH3R3K1A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  7

• Construction:

  Rectangular

• Core Material:

  FERRITE

• DC Resistance:

  0.00111 Ω

• Inductance-Nom (L):

  3.3 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Lead Length:

  5 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  15 mm

• Package Length:

  33 mm

• Package Style:

  PCB Mount

• Package Width:

  29.8 mm

• Rated Current-Max:

  59 A

• Self Resonance Frequency:

  18 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  TIN

• Terminal Placement:

  SINGLE IN-LINE

• Terminal Shape:

  FLAT

• Test Frequency:

  0.1 MHz

• Tolerance:

  10%
