IHDM1008BCEV2R2M20 - Vishay

IHDM1008BCEV2R2M20 Details

• Manufacturer Part Number:

  IHDM1008BCEV2R2M20

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  7.8

• Construction:

  Rectangular

• Core Material:

  IRON ALLOY

• DC Resistance:

  0.0007 Ω

• Inductance-Nom (L):

  2.2 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Length:

  6 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  180 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  21.75 mm

• Package Length:

  25.53 mm

• Package Style:

  Radial

• Package Width:

  20.73 mm

• Packing Method:

  Bulk

• Rated Current-Max:

  63 A

• Self Resonance Frequency:

  69 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  FLAT

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
