IHTH1125KZEB680M51 - Vishay

IHTH1125KZEB680M51 Details

• Manufacturer Part Number:

  IHTH1125KZEB680M51

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  7

• Construction:

  Magnetically Shielded

• Core Material:

  METAL ALLOY

• DC Resistance:

  0.0274 Ω

• Inductance-Nom (L):

  68 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Diameter:

  1.118 mm

• Lead Length:

  4.191 mm

• Lead Spacing:

  16.586 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  28.575 mm

• Package Length:

  10.744 mm

• Package Style:

  Radial

• Packing Method:

  Tray

• Rated Current-Max:

  10.5 A

• Self Resonance Frequency:

  2.95 MHz

• Shape/Size Description:

  CIRCULAR PACKAGE

• Shielded:

  YES

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
