IHTH1500TZEB100M5A - Vishay

IHTH1500TZEB100M5A Details

• Manufacturer Part Number:

  IHTH1500TZEB100M5A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6

• Construction:

  Circular

• Core Material:

  COMPOSITE

• DC Resistance:

  0.0017 Ω

• Inductance-Nom (L):

  10 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Diameter:

  2.87 mm

• Lead Length:

  9.525 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -55 °C

• Package Diameter:

  38.1 mm

• Package Length:

  19.81 mm

• Package Style:

  PCB Mount

• Packing Method:

  Bulk

• Rated Current-Max:

  52.9 A

• Self Resonance Frequency:

  5.7 MHz

• Shape/Size Description:

  CIRCULAR PACKAGE

• Shielded:

  YES

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
