IKH1003000 - Apem

IKH1003000 Details

• Manufacturer Part Number:

  IKH1003000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  APEM Inc

• YTEOL:

  8

• Actuator Color:

  WHITE

• Actuator Material:

  THERMOPLASTIC

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  VERY LOW PROFILE

• Body Breadth:

  4.5 mm

• Body Color:

  BLACK

• Body Height:

  1.5 mm

• Body Length or Diameter:

  13.93 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  .025A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  300VAC V

• Electrical Life:

  1000 Cycle(s)

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  THERMOPLASTIC

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  THERMOPLASTIC

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  10

• Number of Switch Sections:

  10

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TUBE

• Sealing:

  TAPE SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  Tin (Sn)

• Termination Type:

  SOLDER
